Cast Aluminum Entry Doors

Cast Aluminum Entry Doors

  • Material: High-strength 6063-T5 aluminum alloy
    Dimensions: Non-standard, customizable to suit door opening

Whatspp:+86 13961616995
E-mail:jstaisheng@gmail.com

Detail



Due to their durability and aesthetic appeal, cast aluminum doors are increasingly being customized to suit individual home and architectural styles. During the customization process, the quality of communication between the customer and the manufacturer directly impacts the finished product and user experience. Below are several key communication details for your reference.


Basic product parameters
Door leaf thickness >105mm
Profile material Using 6060-T66 high-strength aluminum alloy profile
Profile wall thickness Hinge connection wall thickness>3.0mm, other wall thickness>2.2mm
Surface treatment High-temperature powder coating, true copper paint four-coat, three-bake spraying process
Profile corners Laser welding + glue injection corners
Thermal insulation strips 32MM Technowind
Internal filling A2-B1 flame retardant board (waterproof, fireproof, non-toxic)
Sealing system Automotive-grade EPDM soft and hard composite rubber strips (triple rubber and plastic) with glue fillet welding process



Hardware parameters
Frame and sash connection Taiwanese precision-cast hinges
Optional locks European standard 24 stainless steel primary and secondary locks


1. Confirm Door Dimensions and Opening/Closing Method
Door Opening Dimensions: Accurately measure the door opening height, width, and doorframe depth to avoid mismatches during the customized door.
Opening/Closing Method: Specific choices include hinged, sliding, or other special opening methods, and consider hardware requirements.



2. Clarify Design and Design Requirements
Patterns, Carvings, and Shapes: Provide clear design drawings or reference images to discuss the carving depth, three-dimensional effect, and overall aesthetics.
Structural Reinforcement: For doors with special shapes or large dimensions, discuss the internal frame design in advance to ensure durability and safety.



3. Surface Treatment and Color
Surface treatment: Choose spray coating, paint, or antique finish, and confirm the weather resistance and applicable environment.
Color and texture: Provide color charts or samples for comparison to avoid significant color differences between the actual product and the intended environment.



4. Hardware and Functional Requirements
Locks, hinges, and security features: Confirm the brand, model, and installation location to ensure the door's security and smooth operation.
Additional features: Requirements such as fire protection, noise reduction, and sealing should be specified in advance to facilitate the manufacturer's design and matching.



5. Delivery and Installation Arrangements
Production Lead Time: Understand the timeline from design confirmation to delivery and plan the construction schedule accordingly.
Installation Requirements: Communicate site conditions, door opening dimensions, and installation aids in advance to ensure smooth installation.


As high-end door products, cast aluminum doors offer the following significant advantages:
1. Excellent Security
Explosion-Proof and Burglar-Proof: Solid cast aluminum panels can be up to 6-10mm thick, with some designs reaching 15-20mm. They can withstand high impact and have passed rifle fire tests.
Class A Burglar-Proof Standard: Utilizing a SECC.N5 steel frame and infilled with aluminum honeycomb or polyurethane foam, these doors offer a security level far exceeding that of ordinary security doors.



2. Durability and Weather Resistance
Corrosion Resistance: Made of pure aluminum with a high-temperature paint finish, these doors remain rust-free after a 500-hour salt spray test, making them suitable for humid coastal environments.
Long Life: No splicing or welding required, ensuring high stability and a service life of 20-30 years.



3. Aesthetics and Customization
High-End Appearance: 3D precision carving creates marble or relief patterns, with a glossiness of 92GU (comparable to automotive paint).
Personalized Customization: Custom molds are available, with styles ranging from Chinese to European.



4. Practical Functionality
Low Maintenance: The surface is flame-retardant and stain-resistant, easily cleaned with a damp cloth, requiring no regular maintenance.
Soundproofing and Insulation: Filled with sound insulation or insulation material, it reduces noise by 30-40 decibels.
Environmentally Friendly and Recyclable: Aluminum is 100% recyclable, in line with green building material concepts.



5. Application Scenarios
High-end residential/commercial spaces: such as villas and banks, offering both security and luxury.
Increasing property value: As a high-end building material, it can significantly enhance the overall quality of a building.
